Double Outlets Horizontal Screw Loader Conveyor Easy To Use

Product Categories
Xinxiang jinrui machinery factory
Contact Now

Double Outlets Horizontal Screw Loader Conveyor Easy To Use

  • 1
  • 2

Brand Name : Jinrui/Kunwei

Model Number : LS300

Certification : ISO

Place of Origin : Henan

MOQ : 1 piece

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 50 piece per Month

Delivery Time : 10 work days

Packaging Details : accroding to the machine size packed into different size woodcase

Product name : Double outlets Easy To Use Horizontal LS Screw Loader Conveyor

Diameter : 300mm

Installation : horizontal

Material : Q235B

Application : pellet, powder

Color : gray

Contact Now

Double outlets Easy To Use Horizontal LS Screw Loader Conveyor

Summray of Screw Loader Conveyor

Compared with the GS type screw conveyor, the head and tail bearings of the LS type screw conveyor are moved to the outside of the shell, the hanging bearing adopts the rolling structure, the pulley bearing is exchanged, and the dust-proof sealing device is installed. Good performance, strong wear resistance, low resistance and long life. Sliding bearing bushes include cast copper tiles that need to be lubricated, alloyed and ground cast iron tiles and copper-based graphite oil-less lubricating tiles. The discharge end is equipped with a cleaning device. The whole machine has low noise, strong adaptability, convenient operation and maintenance, and inlet and outlet ports. The location arrangement is flexible.

Double Outlets Horizontal Screw Loader Conveyor Easy To Use

Characteristics of Screw Loader Conveyor

1, convenient maintenance;
2, simple structure;
3,small size of the cross section;
4,can enter and leave materials at any position in the length direction;
5, can use the cover of the tight closed housing to achieve a better sealing effect;
Therefore, screw conveyor is widely used in various industrial sectors to transport a variety of powdered, granular and small materials, such as cement, coal ash, coal, sand, cereals and so on; it is not easy to transport viscous caking materials which are easy to deteriorate.

Technical parameter of Screw Loader Conveyor

Model
Diameter
mm
Pitch
mm
Speed
r/min
Standard
Capacity(m3/h)
Speed
r/min
Standard
Capacity(m3/h)
Speed
r/min
Standard
Capacity(m3/h)
φ0.45
φ0.33
φ0.15
φ0.45
φ0.33
φ0.15
φ0.45
φ0.33
φ0.15
LS200
200
200
100
16.9
12.4
5.6
80
13.5
9.9
4.5
63
10.7
7.8
3.6
LS315
315
315
80
52.9
38.8
17.6
63
41.6
30.5
13.9
50
33.1
24.2
11
LS400
400
355
71
85.3
62.5
28.4
56
67.3
49.3
22.4
45
54.1
39.6
18
LS500
500
400
63
133.2
97.7
44.4
50
105.8
77.6
35.3
40
84.6
62.0
28.2
LS630
630
450
50
188.9
138.5
63.0
40
151.1
110.8
50.4
32
120.9
88.6
40.3

1.Q:How can i choose a suitable model for ourself?

A:pls supply the below information.

1.Transport material and its particle size
2.horizontal transport and inclined transport?If inclined transport,pls let me know the inclined angle.
3.transport distance
4.capacity per hour


2.Q:How is the MOQ.

A:one set can be accepted.
